Built to Standard. Consistant Performance.
We are committed to maintaining the highest standards across every aspect of our business. We uphold the highest levels of excellence throughout our design and manufacturing processes. Every coil is thoroughly pressure tested, carefully inspected, and fully documented prior to dispatch, ensuring consistent quality and reliability.
Core Certifications
PED 2014/68/EU Compliance
All pressurised components comply with the relevant sections of the Pressure Equipment Directive (2014/68/EU). We provide full declarations of conformity and supporting documentation as standard.
- Category-appropriate conformity assessment procedures
- Pressure testing to design code requirements
- CE and UKCA marking where applicable
- Material certificates and weld documentation provided
ATEX 2014/34/EU — Hazardous Area Equipment
We supply coolers and condensers with ATEX-rated components for use in explosive atmospheres. Fans, motors and electrical fittings are certified to the ATEX Directive (2014/34/EU) for Zone 1 and Zone 2 classifications.
- ATEX-certified fans and motors (Zone 1 / Zone 2)
- Equipment Group II, Category 2G and 3G available
- Explosion-proof junction boxes and wiring
- Full ATEX documentation and declarations of conformity
PED Category Breakdown
The Pressure Equipment Directive classifies equipment into four categories based on operating pressure, volume and fluid group. The higher the category, the more rigorous the conformity assessment. Below is how our products typically fall within PED classifications.
| Category | Pressure Range | Conformity Assessment | Typical Products |
|---|---|---|---|
| Category I | PS ≤ 0.5 bar above thresholds | Internal production control (Module A) | Low-pressure water coils, small heating batteries |
| Category II | PS up to 10 bar (typical) | Internal production control + monitoring (Module A2) | Standard chilled water coils, LPHW coils, dry coolers |
| Category III | PS up to 25 bar | Module B+D or B+E (Notified Body involvement) | High-pressure steam coils, DX refrigerant coils |
| Category IV | PS > 25 bar or hazardous fluids | Full quality assurance (Module G or H1) | CO₂ systems, high-pressure condensers, ATEX applications |
Industry-Specific Standards
NHS HTM & SHTM Compliance
Coils designed and documented in accordance with Health Technical Memoranda for AHUs, chilled water systems and critical ventilation in healthcare environments.
Low-GWP Refrigerant Ready
Coil designs optimised for next-generation, low global-warming-potential refrigerants including R32, R454B and R1234ze — future-proofing your installation.
Hygienic & Food-Safe Construction
Stainless steel frames, cleanable coil layouts, optional Heresite or epoxy coatings, and compliance with food processing hygiene requirements.
Documentation Provided With Every Order
Documentation Provided Upon Request
Download Product Documentation
Browse our catalogue brochures and operation & maintenance manuals. For project-specific documentation, contact our engineering team.
Need Compliance Documentation?
Talk to our engineering team about your regulatory or documentation requirements — we'll make sure you get what you need.
Request Documentation
