    Bespoke Free Coolers manufactured by HC Coils

    Free Coolers

    Ambient air cooling to reduce compressor run hours and energy consumption when conditions allow.

    PED CompliantISO 9001 Certified

    Free Cooling Calculator

    Free cooling system diagram at 15°C ambient air temperature, showing incoming water, the three-way valve and the chiller outlet

    Free Cooling Performance

    Using ambient air to reduce chiller demand and save electrical power.

    Ambient Air Temperature

    °C

    15°C

    Free Cooler
    Cooling Duty

    kW

    Chiller
    Cooling Duty

    kW

    Electrical
    Power Savings

    kW

    Total Power Used31.12 kW
    065
    Chiller Power20.72 kW
    065

    Electrical Power
    Saved

    28.88kW

    (48.13%)

    Free Coolers

    Free coolers utilise low ambient air temperatures to provide cooling without the need for mechanical refrigeration. HC Coils designs and manufactures bespoke free cooling systems that integrate into your existing chilled water or glycol loop, reducing compressor run hours and energy consumption. When ambient conditions are favourable, the free cooler handles the full cooling load. As temperatures rise, the system transitions back to mechanical cooling. This hybrid approach delivers significant energy savings — particularly in the UK climate where free cooling hours are substantial.

    Technical Specifications

    Cooling Method

    Ambient Air (No Compressor)

    Best At

    Low Ambient Temps

    Test Pressure

    16 bar (water)

    Energy

    Excellent (Passive)

    Fan Options

    EC Variable Speed

    Key Advantages

    • Reduced compressor hours — offloads chiller duty during cooler ambient periods.
    • Hybrid operation — transitions between free cooling and mechanical cooling based on ambient temperature.
    • Bespoke sizing — designed to your duty, loop temperatures and ambient conditions.
    • Simple systems — fewer moving parts, straightforward maintenance.

    Typical Applications

    Data Centres

    Commercial HVAC

    Process Cooling

    Server Rooms

    Retail

    Bespoke free cooler with top-mounted fans and exposed copper pipework on the factory yardCopper header pipework and actuated valve assembly on a bespoke free coolerV-bank free cooler with vertical manifold pipework, green flanged connections and a blue-handled valve in a factory setting
    Get Engineering Advice on Free Coolers

    Downloads

    Product Catalogue

    Full specifications, dimensions and performance data.

    Download PDF

    Operation & Maintenance Manuals

    Installation, commissioning and maintenance instructions.

    Download O&M

    Standards & Accreditations

    All our products meet exceptional standards, achieved by testing and inspecting our coils and products regularly and adhering to strict procedures.

    Learn More

    What Our Clients Say

    At Sovereign Air Movement Ltd we have used H&C Coils for over 25 years now. Very efficient in turning projects round. Quality Coils, competitive prices along with very good lead times.

    Kevin

    Sovereign Air Movement Ltd

    When a cooler failed on site, HC Coils delivered a new custom replacement. They understood our requirements and got us back on track without delay.

    James T

    Facilities Manager — Data Centre

    Common Questions — Free Coolers

    A dry air cooler rejects heat from a closed-loop fluid circuit (water or glycol) to ambient air using finned-tube heat exchangers and axial fans. No water is consumed in the cooling process, and no chemical water treatment is required.
